K&F 150HP Agriculture Tractor SJH7150

150HP Agriculture Tractor KF 7150

  • The year round workhorse to get the job done day in and day out.



    Equipped with YTO engine, offers 140 and 180 HP PTO which delivers adaptability, performance, and the power.

products profile

K&F 140HP Farm Tractor SJH SP7140

  1. YTO engine provides excellent performance along with low fuel consumption and high power return ratio;
  2. 16F+8R shuttle shift transmission can provide a reasonable velocity distribution, and a good operating adaptability;
  3. Optional Germany LUK independently controlled dual clutch, gives you reliability and high torque transmission during gear shifting;
  4. Adjustable wheel tread, air brake and deep tread power tires (optional).

products details

K&F 150HP Agriculture Tractor KF 7150

K&F 150HP Agriculture Tractor SJH7150.Presenting the SJH SP series wheel tractors, our ultimate power machine. They are the year round workhorse you need to get the job done day in and day out. Equipped with YTO engine, the SP 7100 series offers 140 and 150 hp PTO which delivers you adaptability, performance, and the power you need and however you need it.

140HP Farm Tractor SJH SP7140.Presenting the SJH SP series wheel tractors, our ultimate power machine. They are the year round workhorse you need to get the job done day in and day out. Equipped with YTO engine, the SP 7100 series offers 140 and 150 hp PTO which delivers you adaptability, performance, and the power you need and however you need it.

Technical parameters

Model KF 7140 KF 7150 KF 7160 KF 7180
Overall dimension(mm) 5060 (L) 4800 (L) 4850 (L)
2345 (W) 2545 (W)
2995 (H) 3230 (H)
Wheel Base (mm) 2580 2600
Min.Ground Clearance (mm) 470
Wheel Tread (mm) Front 1900 (1720-2100)
Rear 1850 (1720-2300)
Structure Weight (kg) 5230 5300
Counter weight (kg) Front 400
Rear 200
Engine Model YTO LR6M3Z-23 LR6M3LR22/1177 LR6M3LR22/1324
Cylinders 6
Rated Power(kW) 103 110.3 118 132.4
Rated Speed (rpm) 2300 2200
Max traction force(kN) 32 35 32.5
Max PTO power(kW) 84.5 87.5 99.96 106
Tyre Front 13.6-24 14.9-26
Rear 18.4-34 18.4-38
Gearbox 16F+8R
Speed(km/h) 1.37~32.94 2~31.5
