Forage Harvester 4QZ-18
-
Expertly harvest and process crops with the Forage Harvester 4QZ-18.
With its precision and speed, this harvester is the perfect solution for any agricultural operation.
products profile
products details
The Forage Harvester 4QZ-18 is a reliable and efficient machine for harvesting crops.
Its precision cutting technology and adjustable settings ensure optimal harvest quality.
Increase your yield and efficiency with the Forage Harvester 4QZ-18.
Technical parameters
| Model | 4QZ-18 | |
| Dimensions in working state (L*W*H) (mm) | 8300*3560*5630 | |
| Structural quality (kg) | 12060 | |
| Supporting engine | Rated power (kW) | 264.8 |
| Rated speed (r/min) | 2200 | |
| Working width (mm) | 3300 | |
| Wheel track | Guide wheel (mm) | 2240 |
| Drive wheel (mm) | 2350 | |
| Wheel base (mm) | 2680 | |
| Guide wheel tire specification (self-propelled) (mm) | 400/70R24 | |
| Driving wheel tire specification (self-propelled) (mm) | 23.1-26 | |
| Straw shredding mechanism type | Roller | |
| Operating speed range (km/h) | 2-6 | |
| Cut length (mm) | 7, 10, 12, 14, 16, 18, 20, 22, 25 | |
| Grain breaking type | Roller | |
| Header cutter type | Rotary Disc Knife | |
